IC434 Flame and B33 Horsehead Nebulae in [SII], Ha and NIR light

click on image to enlarge

[SII] Ha NIR: RGB

click on image to enlarge

Ha only

Taken on October 11, 2003 from my backyard in Castro Valley, Ca.

Astro-Physics Traveler f/6 with Astro-Physics 0.75X Telecompressor (F=457.5mm total, f/4.5)

Finger Lakes Instrumentation IMG1024S "Dream Machine"  Imaging Camera at -40deg C.

Astro-Physics 80mm guidescope

SBIG ST7E guide camera

Astro-Physics AP1200GTO mount

Finger Lakes Instrumentation DF2 Digital Focuser

Finger Lakes Instrumentation CFW1 Filter Wheel

Custom Scientific Narrowband Emission Line Filters

   [Sulfur II]                     672.4nm  3nm FWHM

   Hydrogen alpha        656.3nm  3nm FWHM

  B+W Type 93 NIR filter (longpass, 850nm cut in)

22 exposures of one minute each through Ha filter

20 exposures of one minute each through [SII] filter

20 exposures of 30 seconds each through NIR filter

52 minutes total exposure time

Maxim 3.20 used for image capture

Sigma pre-beta 11 used for darks, biases, flats, combines

Photoshop 7 used for final adjustments
