M27 Dumbbell Nebula in Hydrogen Alpha Light

click on image to enlarge

Ha only

click on image to enlarge

Ha only (boosted processing to show the outer ring)

click on image to enlarge

Ha and [OIII] data (Ha = Red, Green = Blue = OIII)



taken on August 28, 2003 from Fremont Peak State Park, near San Juan Bautista, Ca. ([OIII data])and on September 1, 2003 from my backyard in Castro Valley, Ca. (Ha data)

Celestron C14 imaging scope @ f/11 (F=3910mm)

Finger Lakes Instrumentation IMG1024S imaging camera @-30C (Ha) and at -27C ([OIII])

RCOS Optical Systems Dichroic Beam Splitter

SBIG ST7E Guide camera controlling

SBIG AO7 Adaptive Optics System

Astro-Physics AP1200GTO mount

Finger Lakes Instrumentation CFW1 Color Filter wheel

Custom Scientific Narrowband Emission Line Filters

   Hydrogen alpha        656.3nm  3nm FWHM

   [Oxygen III]                 500.7nm  3nm FWHM

Eight exposures of fifteen minutes through Ha filter, three exposures of 10 minutes through [OIII] filter

Total exposure time: 2 hours 30 minutes

Maxim DL 3.20 used for image acquisition, calibration, DDP, color combination

CCDSOFT 5.00.071 used for guiding/AO7 control

SIGMA Prebeta 11 used for darks, flats and image stacking
